Rata Resistive Load Bank Supplier-1
Product Overview
- Rata R100 kW / 400 V / 50 Hz portable resistive load bank (2024 model) for generator set testing and on-site electrical load simulation.
- Cabinetized, single-container design including dry resistive elements and electrical control components; portable (80 kg) with dimensions 700 × 500 × 960 mm.
- Control via touch‑screen PLC and remote PC (RJ45) using Rata-supplied software; quick‑connect power cables for fast setup.
- Built to international, ship, military and telecommunication standards; operating ambient −20 °C to 50 °C.
Product Features
- Power rating: 100 kW at 400 V / 50 Hz; minimum step 1 kW; customizable load step configuration per customer.
- Resistive element: 8020 Ni‑Cr alloy finned resistors; forced air cooling with horizontal discharge.
- Load control/communication: touch screen + remote PC control, PLC system, RJ45 interface and supplied software.
- Protection features: short circuit, overcurrent, high temperature and emergency stop; continuous duty mode.
- Accuracy and balance: loading accuracy ≤ 3%, three‑phase unbalance ≤ 3%; measurement/display accuracy: display 0.5, sampling 0.2.
- Expandable: parallel expansion of multiple load containers for higher capacity.
Product Value
- Provides accurate, repeatable resistive loading to verify generator sets, switchgear and protection systems under real load conditions.
- Portable and quick‑connect design reduces setup time and on-site labor costs.
- Remote control and PLC enable automated test sequences, data capture and safer hands‑off operation.
- Robust protection and compliance with multiple standards reduce risk during testing and support regulatory/contractual requirements.
- Modular expandability supports flexible testing from small to large systems without multiple different units.
Product Advantages
- Built and quality‑controlled by Rata (est. 2013) — company credentials include 18 patents, ISO 9001/14001/45001 and CE certifications and multiple software copyrights.
- High build quality and refined surface finish with strict QA for reliable long‑term operation.
- Customizable load steps, quick connectors and standard communications simplify integration into customer workflows.
- Proven export experience and established after‑sales service network; experienced engineering and production team.
- Designed for rugged field use with F insulation class and wide ambient operating range.
Application Scenarios
- Generator set load testing and commissioning (factory, rental fleets, field).
- Routine maintenance and acceptance testing of backup power systems, UPS and switchgear.
- Shipboard and telecom site testing (meets ship and telecommunication standards).
- Military and engineered systems testing (meets military standards).
- Industrial plants, power stations and electrical labs requiring controlled resistive load conditions or scalable load banks.
