21kW rack-mounted load bank
A 21kW rack-mounted load bank (Model No. RTLB21-RM) is a precision tool for electrical system testing, striking an ideal balance of compact power, reliability, and adaptability. Originating from China, it excels in validating UPS, generators, and electrical infrastructure, making it a go-to solution for industries needing targeted, efficient load testing.
5.0
Brand:
RATA
Factory Price:
Negotiate
Supply Ability:
200,000 Piece/Pieces per Month
Port:
Shanghai and Guangzhou are both available
Payment Terms:
L/C,Cash,Western Union,T/T, Paypal
Min.Order Quantity:
1 pcs
ODM & OEM:
Available
Certification:
CE 60204 Standard
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Introduction
Built with finned heating tubular resistors and a dual-channel power source, this load bank delivers 21kW of capacity across three load steps (each 1+2+4kW at 230Vac).
It ensures accuracy with ±5% voltage tolerance (short-term operation) and ±3% load element tolerance, while features like thermal emergency cut-out, air circuit breaker protection, and forced-air cooling (706 CFM via four 150mm fans) guarantee safe, stable operation even in demanding environments (up to +50°C ambient temperature).
Enclosure drawings (mm)
未标题-1 (16)
Main Parameters
| Description | |
| Model No. | RTLB21-RM |
| Country of origin | China |
| Max capacity | 21kW |
| L1: 1+2+4kW 230Vac L2: 1+2+4kW 230Vac | |
| Load step | L3: 1+2+4kW 230Vac |
| Resistors type Power source | Finned heating tubular resistor Dual (Channel A / Channel B) |
| Voltage Tolerance (Short Term Operation) | 5% |
| Load Element Tolerance | ± 3% |
| Load Connections | TYP281 ( 32A three-pins industrial connector) |
| Protection | Thermal emergency cut out |
| Air circuit breaker protection(40A) Dual power supply interlock protection 80℃ red light alert | |
| 90℃ trip off | |
| Cooling method | Air forced cooling |
| Fans Nos. | 150mm diameters cooling fans 4pcs |
| Airflow volume | 706CFM * 4 |
| Airflow direction | Horizontal |
| Rated maximum ambient temp. operation | +50°C / +122°F |
| Rated minimum ambient temp. operation | -20°C / -4°F |
| Altitude rating | <2000m [m.a.s.l.] |
| Control chamber IP rating | IP 23 |
| Portability | 4 universal castors+ 2 Foldable handle clips |
| Enclosure dimensions | |
| Width(mm) | 492 |
| Depth(mm) | 478 |
| Height(mm) | 691mm |
| Weight(KG) | 48 |
| Load bank control system | |
| Local control | Potentiometer power rotation for L1/ L2/L3 seperately |
| Remote control | Siemens PLC with RJ45 communication interface |
Main parts
IMG_8265 拷贝
IMG_8266 拷贝
IMG_8218 拷贝
IMG_8241 拷贝
IMG_8242 拷贝
IMG_8267 拷贝
