Dummy Load Bank Dummy Load Bank for Generator Testing From China
Product Overview
Rata Dummy Load Bank for Generator Testing is a containerized, resistive load bank designed for large generator commissioning and testing. The standard model provides 2000 kW (2 MW) rated power at 6000 VAC (three‑phase, three‑wire) and is built for outdoor use with IP54 protection. The unit is factory‑assembled, hoistable via four top lift lugs, and shipped wrapped for export.
Product Features
- Resistive-only 2000 kW capacity with modular load steps (50+50+100+100+200+500+500+500 kW).
- 6000 VAC supply connection using tin‑plated copper bus; control voltage 380 VAC.
- Container design with forced‑air cooling, horizontal air intake and vertical hot‑air outlet, and marine‑style waterproof ducts/mesh.
- Siemens PLC local and remote control; RJ45 (Modbus TCP) interface standard, RS485/RS232 optional; operation software and data logging/printing; digital meters for volts, amps, kW, PF, Hz.
- 8020 Ni‑Cr alloy finned resistors, comprehensive protections (high temp, low air flow, phase sequence, overcurrent/overvoltage, short circuit, fan interlock, smoke alarm, temp/humidity control, access control, emergency stop).
Product Value
The load bank enables safe, accurate, and repeatable full‑load and staged testing of large generators without relying on site loads, reducing commissioning time and risk. Its robust, weather‑protected container design allows reliable outdoor operation at remote sites (e.g., oil fields), protecting assets and validating generator performance under controlled conditions. Remote control, data logging, and factory acceptance testing/training services add operational confidence and documentation for clients.
Product Advantages
- Built for durability and high tolerance with industrial‑grade materials and Ni‑Cr resistors.
- Flexible control and communications (local panel or remote PC, Modbus TCP/RS485/RS232), multilingual software and data export.
- OEM/ODM customization (design, logo, color) and global service: 7×24 after‑sales support, factory acceptance testing, free on‑site training during visits.
- Proven supply chain and partnerships (ABB, Schneider, Omron, Siemens, Phoenix Contact, Delixi) plus multiple delivery centers for global logistics.
- Comprehensive safety and diagnostic protections plus ease of installation and maintenance (bolted air duct, removable covers).
Application Scenarios
- Load testing, commissioning and routine maintenance of large diesel or gas generators (including oil‑field generator units).
- Factory acceptance testing and performance verification of gensets and power systems.
- Emergency generator system validation for industrial plants, utilities, and large commercial sites.
- Temporary load simulation for power system studies, UPS and standby system checks, and training exercises.
