High Voltage Resisitive Load Bank by Rata-1
Product Overview
**Product Overview:**
Product Features
The High Voltage Resistive Load Bank by Rata is a powerful testing device designed for various applications in high-voltage environments. It features robust construction that supports long-term, continuous operation for accurate load testing.
Product Value
**Product Features:**
Product Advantages
- Advanced design with air cooling for safe and reliable operation.
Application Scenarios
- Equipped with a Ni-Cr alloy finned resistor for enhanced pressure resistance.
- Supports both local panel and remote PC control, offering flexibility in operation.
- High protection levels against temperature, low air volume, and other potential hazards.
- Meets international and military standards for quality and performance.
**Product Value:**
Rata's load bank provides essential testing capabilities needed for maintenance and performance evaluation of electrical systems. Its design and high build quality ensure longevity, making it a valuable long-term investment for industries requiring precise power system assessment.
**Product Advantages:**
- Compact size and easy handling with long service life and low power consumption.
- High load test accuracy without preparation time required for testing.
- Provides continuous operation with stable performance, ideal for ongoing industrial use.
- Customizable design options to meet specific customer requirements.
- Supported by superior after-sales service and technical support for efficient problem resolution.
**Application Scenarios:**
- Power system maintenance and testing, crucial for assessing transformers, switches, and circuit breakers.
- Electrical testing for components in power engineering and manufacturing sectors.
- Research and laboratory testing environments for electrical performance studies.
- Additional applications in communication systems, motors, generators, and various electronic devices.
- Specifically developed solutions for gas-fired power plants, enhancing operational efficiency.
Data Sheet
|
5MW Resistive Load Bank Data Sheet |
|
|
Product name |
5000kW resistive load bank; |
| Model number | RT5000kWLB; |
| Design | Container type with air duct for outdoor use; |
|
Rated power |
AC 11kV. Connected with tin plated copper bar. Other customized voltages are available; |
| Control power |
AC380V,3 phase 4 wire,connected with quick coonector/terminal; |
| Frequency | 50Hz/60Hz; |
| Loading accuracy | ≤ 3%; |
| 3 phase balance | Unbalance degree ≤ 3%; |
| Duty cycle | Continuous work |
| Insulation | F |
|
Operation mode |
1)Local panel switching operation 2)Remote PC operation(Mod bus TCP communication protocol,PLC system,operation software,support load data save and printing); |
|
Load steps |
100kW resolution;100kW+200kW+200kW+500kW+1000kW+1000kW+1000kW+1000kW |
|
Resistor |
8020 Ni-Cr alloy finned resistor; |
|
Cooling system |
Forced air cooling;horizontal air intake and vertical outlet;Axial fan,noise less than 80dB at 3m distance; |
| Enclosure | Q235 steel,powder coated. |
|
Protection |
High temperature,low air volume,phase sequence,short circuit,fan interlock,access control,temperature and humidity control,emergency stop; |
|
Digital meter |
Voltage,current,power,power factor and frequency; |
|
Load expansion |
Parallel expansion of multiple loads; |
|
Standard |
Meet international standard,ship standard,military standard and telecommunication standard |
|
Movement |
Lift lugs on the top |
|
Color |
RAL 7035(industrial grey) |
| Dimensions | 12000mm*2530mm*2600mm (L*W*H) |
| Weight | 18000Kg |
|
Ambient temperature |
-20℃ to 50℃ |
|
Humidity |
Up to 100% |
|
Altitude |
Up to 2500m |
|
Atmospheric pressure |
86 to 106kPa |
| Warranty period | 12 months start from commissioning at clients' ste |
| Packing | Wrapping film |
Design drawing:
Production details:
Device and circuit layout 1:
Device and circuit layout 2:
