Rata Dc Resistive Load Bank Supplier for Sale
Product Overview
Here is a summarized overview of the product “Rata DC Resistive Load Bank Supplier for Sale” based on the detailed introduction:
Product Features
**Product Overview**
Product Value
The Rata DC resistive load bank is a high-power electrical testing device, exemplified by its 5MW/11kV AC resistive load bank model. It is designed primarily for use in power stations such as gas power plants, featuring a container-type outdoor design with robust construction. The product supports both local and remote PC control for flexible operation and is built to handle continuous heavy-duty loading.
Product Advantages
**Product Features**
Application Scenarios
- Rated power of up to 5000kW at 11kV with customizable voltage options.
- High precision loading accuracy (≤3%) and balanced 3-phase power.
- Multi-step load capability with fine resolution for load adjustments (100kW steps).
- Uses durable 8020 Ni-Cr alloy finned resistors and forced air cooling system with horizontal air intake and vertical air outlet for efficient temperature control.
- Equipped with comprehensive protection systems (high temperature, low air volume, phase sequence, short circuit, etc.) and digital meters displaying voltage, current, power, power factor, and frequency.
**Product Value**
The load bank enables reliable, accurate simulation of electrical loads to verify the capacity, stability, and performance of power generation and distribution systems. By ensuring electrical equipment works under full load conditions, it helps identify potential failures early, reducing downtime and maintenance costs. Its customizable design and digital control systems offer enhanced operational flexibility and data management.
**Product Advantages**
- Manufactured with certified, high-quality materials and advanced production technology ensuring consistent performance and durability.
- Waterproof and animal-proof design with powder-coated Q235 steel enclosure for outdoor use.
- Strong support network including 24/7 aftersales service, on-site commissioning, and user training.
- Compliance with international, military, and ship standards guarantees broad applicability and reliability.
- Modular load expansion and remote PC control via Modbus TCP protocol improve operational integration.
**Application Scenarios**
- Testing and commissioning of power generation plants, including gas power stations.
- Verification and maintenance of substations and electrical distribution systems.
- Load simulation during factory acceptance tests for electrical equipment manufacturers.
- Temporary load application for grid operators to balance and monitor systems.
- Suitable for use in harsh outdoor environments within industrial, utility, and military sectors.
This summary captures the key points for your understanding or promotion of the Rata DC resistive load bank product.
Products Description
|
5MW Resistive Load Bank Data Sheet |
|
|
Product name |
5000kW resistive load bank; |
| Model number | RT5000kWLB; |
| Design | Container type with air duct for outdoor use; |
|
Rated power |
AC 11kV. Connected with tin plated copper bar. Other customized voltages are available; |
| Control power |
AC380V,3 phase 4 wire,connected with quick coonector/terminal; |
| Frequency | 50Hz/60Hz; |
| Loading accuracy | ≤ 3%; |
| 3 phase balance | Unbalance degree ≤ 3%; |
| Duty cycle | Continuous work |
| Insulation | F |
|
Operation mode |
1)Local panel switching operation 2)Remote PC operation(Mod bus TCP communication protocol,PLC system,operation software,support load data save and printing); |
|
Load steps |
100kW resolution;100kW+200kW+200kW+500kW+1000kW+1000kW+1000kW+1000kW |
|
Resistor |
8020 Ni-Cr alloy finned resistor; |
|
Cooling system |
Forced air cooling;horizontal air intake and vertical outlet;Axial fan,noise less than 80dB at 3m distance; |
| Enclosure | Q235 steel,powder coated. |
|
Protection |
High temperature,low air volume,phase sequence,short circuit,fan interlock,access control,temperature and humidity control,emergency stop; |
|
Digital meter |
Voltage,current,power,power factor and frequency; |
|
Load expansion |
Parallel expansion of multiple loads; |
|
Standard |
Meet international standard,ship standard,military standard and telecommunication standard |
|
Movement |
Lift lugs on the top |
|
Color |
RAL 7035(industrial grey) |
| Dimensions | 12000mm*2530mm*2600mm (L*W*H) |
| Weight | 18000Kg |
|
Ambient temperature |
-20℃ to 50℃ |
|
Humidity |
Up to 100% |
|
Altitude |
Up to 2500m |
|
Atmospheric pressure |
86 to 106kPa |
| Warranty period | 12 months start from commissioning at clients' ste |
| Packing | Wrapping film |
