Rata Load Bank Products Wholesale - Rata
Product Overview
Rata Load Bank Products Wholesale - Rata offers resistive inductive load banks for testing the power factor of diesel generator sets, with a focus on design and quality.
Product Features
The load banks come with various features such as high loading accuracy, multiple control options, parallel expansion capabilities, and compliance with international standards.
Product Value
Rata provides 24/7 after-sales service, OEM/ODM options, and partners with reputable brands. They offer lifelong technical support and maintenance services.
Product Advantages
The load banks have a durable design, high-quality components, advanced cooling systems, and extensive safety features for efficient and reliable operation.
Application Scenarios
The load banks are suitable for shipyard generator load tests, marine turbine inspections, aviation power supply checks, and other critical power supply inspections in various industries.
Products Description
|
Product name |
500kW/375kvar Resistive Inductive Load Bank; |
| Model number | RT625kVALB; |
| Design | Indoor design |
|
Rated power |
AC 380V,400V,415V,440V,690V,customized. 3 phase 4 wire. Connected with tin plated copper bar; |
| Control power |
AC380V,3 phase 4 wire,connected with quick coonector/terminal; |
| Frequency | 50Hz/60Hz; |
| Loading accuracy | ≤ 3%; |
| 3 phase balance | Unbalance degree ≤ 3%; |
| Duty cycle | Continuous work |
| Insulation | F |
|
Operation mode |
1)Local panel switching operation 2)Remote PC operation(Mod bus TCP communication protocol,PLC system,operation software,support load data save and printing); |
|
Resistive load steps |
1kW resolution;1kW+2kW+2kW+5kW+10kW+10kW+20kW+50kW+100kW+100kW+100kW+100kW; |
|
Resistor |
8020 Ni-Cr alloy finned resistor; |
| Inductive load steps | 1kvar resolution;1kvar+2kvar+2kvar+5kvar+5kvar+10kvar+10kvar+20kvar+20kvar+50kvar+50kvar+100kvar+100kvar; |
| Inductor | 3 phase inductor; |
|
Cooling system |
Forced air cooling;horizontal air intake and vertical outlet;Axial fan,noise less than 80dB at 3m distance; |
| Enclosure | Q235 steel,powder coated. |
|
Protection |
High temperature,low air volume,phase sequence,short circuit,fan interlock,emergency stop; |
|
Digital meter |
Voltage,current,power,power factor and frequency; |
|
Load expansion |
Parallel expansion of multiple loads; |
|
Standard |
Meet international standard,ship standard,military standard and telecommunication standard; |
|
Movement |
Lift lugs and forklift holes |
|
Color |
RAL 7035(industrial grey); |
| Dimensions | 2100mm*1530mm*1955mm (L*W*H) |
| Weight | 1850Kg |
|
Ambient temperature |
-20℃ to 50℃ |
|
Humidity |
Up to 100% |
|
Altitude |
Up to 2500m |
|
Atmospheric pressure |
86 to 106kPa |
