Product Overview

- R200 kW resistance load bank (R200kW/AC400V/50Hz, PF≈1.01) from Rata Load Bank Company; compact, space-efficient cabinet with two-color (black frame, yellow cover) design. Controls include local manual knob and Siemens touch screen; remote PC control is optional.

Rata Rata Load Bank Rata Load Bank Company-3 6

Rata Rata Load Bank Rata Load Bank Company-3 7

Product Features

- Resistive load bank with rational structural layout for efficient space use.

- Dual control modes: local touch-screen operation and optional remote PC control with data saving and printing.

- Supplied with operation & maintenance manual, acceptance certificate, inspection report, electrical schematic and PC software.

Product Value

- Provides reliable, recordable load testing for commissioning, maintenance and verification of power equipment.

- Improves test accuracy and traceability through saved/printable load data.

- Compact, user-friendly design reduces installation footprint and simplifies on-site operation.

Rata Rata Load Bank Rata Load Bank Company-3 8

Rata Rata Load Bank Rata Load Bank Company-3 9

Product Advantages

- Manufactured with professional core technologies and strict quality oversight.

- Backed by Rata (Deyang Rata Technology Co., LTD) expertise: strong R&D, export experience and growing customer service capacity.

- Flexible control options (local Siemens touch screen + optional PC) and complete documentation/software package.

Application Scenarios

- Load testing and commissioning of generators, UPS systems, switchgear and power distribution equipment.

- Routine maintenance and performance verification in industrial plants, data centers, utilities and manufacturing facilities.

- Field and factory testing where portable, recordable resistive loads are required.

Rata Rata Load Bank Rata Load Bank Company-3 10

Data Sheet

Note: all parameters are for reference only and can be customized
Product name	200kW load bank
Specifications	R200kW/400V/50Hz
Formation	One load bank(Including dry resistance load, electrical control components, measurement and control system)
Load steps	1kW, 22kW, 5kW, 210kW, 20kW, 50kW, 100kW
Load connection	Copper bar
Resistor	Each resistance element: insulation impedance DC1000V/100MΩ above Withstand voltage AC 2000V for 5min Resistance error of each resistance tube: ±3%
Load control	Local touch screen control and remote PC control
Loading accuracy	≤ 3%
Three phase balance	Unbalance degree ≤ 3%
Minimum step	1kW
Working mode	Continuous work
Load protection	Short circuit, overcurrent, high temperature, fan fault protection
External power	380V/50Hz
Cooling mode	Forced air cooling, horizontal air outlet
Insulation class	F
Measurement accuracy	The display accuracy is 0.5,the sampling accuracy is 0.2
Electrical parameter display	Three phase voltage, three-phase current, frequency, power, etc
Load expansion	Parallel expansion of multiple loads
Standard	Meet international standard, ship standard, military standard and telecommunication standard
Transport	The load bank has a load-bearing lifting hole, which meets the requirements of long-distance transportation
Color	Customized
Dimensions	800mm1100mm1200mm (LWH)
Weight	100Kg
Ambient temperature	-20℃ to 50℃
Humidity	Up to 100%
Altitude	Up to 2500m
Atmospheric pressure	86 to 106kPa

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
