Product Overview
- Model: RTLB06-RM (Rata 6 kW rack-mounted load bank).
- Designed for standard 19" data center racks (483 mm x 550 mm, 8U) and single-phase 230 Vac, 50–60 Hz operation.
- Compact, steel enclosure (approx. 35 kg) with three C20 load outlets and manual control via Schneider circuit breaker.
- Supplied with factory test report, electrical drawings, operation manual; 3-year warranty and 24/7 technical support.
Product Features
- Rated capacity: 6 kW with six 1 kW load steps (customizable stepping).
- Load element: finned resistors, ±5% tolerance; insulation test voltage 500 Vac.
- Cooling: forced-air, horizontal flow via 4 fans (total ~1,640 CFM); inlet–outlet ΔT up to 40°C (typical ~10°C).
- Protections: thermal emergency cut-out, over-temperature alarm; control chamber IP23.
- Environmental ratings: operation 0–75°C, storage 0–85°C, altitude < 2000 m.
- Optional/additional: digital meters (V/A/P), adjustable/displayed airflow, MCB control, customizable enclosure color.
Product Value
- Provides accurate, repeatable power loading to validate data center power distribution, UPS, and cooling systems.
- Enables realistic server-load simulation for commissioning, acceptance testing, capacity planning, and HVAC verification.
- Improves operational safety and reliability during testing with built-in protection and certified insulation.
- Scalable solution: multiple units can be paralleled to simulate larger clusters, supporting phased expansion and renovation testing.
- Reduces risk and downtime by allowing controlled, continuous 24-hour testing with robust cooling and protections.
Product Advantages
- Rack-mounted 8U form factor integrates directly into existing 19" racks without special footprint.
- High airflow and horizontal ventilation design that aligns with data center airflow architectures—minimizes disturbance to room cooling.
- Precise step control (±5% tolerance) and customizable configurations for flexible test scenarios.
- Strong safety and compliance features (thermal shutdown, IP23, 500 Vac insulation test) and reliable components (Schneider breaker).
- Backed by factory documentation, 3-year warranty, and responsive 24/7 technical support.
Application Scenarios
- Data center commissioning and periodic load testing of server racks, PDUs and UPS systems.
- HVAC and CRAC performance validation by recreating realistic server heat loads and measuring cooling effectiveness.
- Capacity planning and stress testing during data center expansion or renovation.
- Parallel multi-unit setups for large-scale cluster load simulation and power infrastructure verification.
- Maintenance, acceptance testing, and continuous operation scenarios requiring long-duration, controlled resistive loading.
