Product Overview
1) Product overview
Product Features
- The Rata R2500kW / L2000kvar resistive–inductive load bank is a 3‑phase, container‑type power load test device (400V/690V configurable) designed primarily for radar load test platforms and general power system testing.
Product Value
- It integrates resistive and inductive sections plus a control system, supports continuous duty, and is built for long operational life under strict quality control.
Product Advantages
2) Product features
Application Scenarios
- Ratings: 2500 kW resistive and 2000 kVAr reactive, 3‑phase 4‑wire, selectable AC 380/400/415/440/690 V, 50/60 Hz.
- High resolution step control: resistive steps to 1 kW resolution (composite step bank) and inductive steps to 1 kVAr resolution. Loading accuracy ≤ 3% and 3‑phase balance/unbalance ≤ 3%.
- Control: local panel or remote PC/PLC operation with Modbus‑TCP, data save/print capability. Parallel expansion of multiple units supported.
- Cooling & construction: forced horizontal intake / vertical outlet air cooling, axial fans (noise < 80 dB@3 m); Q235 powder‑coated steel enclosure, insulation class F.
- Protections & meters: over‑temperature, low air volume, phase sequence, short circuit, fan interlock, emergency stop; digital metering for voltage, current, power, PF, frequency.
3) Product value
- Provides accurate, repeatable full‑load and partial‑load testing for generators, UPS, and power systems, reducing commissioning and maintenance risk.
- Saves test preparation time and supports long continuous operation, improving equipment uptime and producing measurable economic return.
- Scalable (parallel expansion) and data‑capable control reduce manual intervention and support traceable test records.
4) Product advantages
- High-capacity combined resistive/reactive capability in one container simplifies on‑site testing of inductive and resistive loads.
- Fine resolution and ≤3% accuracy for precise load simulation; continuous duty and rugged construction for long service life.
- Flexible control (local/remote), industry communication protocol (Modbus‑TCP), and compliance with international/ship/military/telecom standards.
- Manufacturer strengths: mature production technology, strict quality control, customer‑driven product improvements, and convenient logistics/support.
5) Application scenarios
- Radar load test platforms and military test benches.
- Generator and prime mover commissioning, routine load testing, and acceptance tests.
- Telecom and data‑center backup power testing, UPS maintenance, and battery/inverter validation.
- Shipboard and marine power system testing (ship standard compliance), industrial plant maintenance, and any large‑scale power system load simulation.
