Data Sheet
Note: all parameters are for reference only and can be customized | |
Product name | 600kW load bank |
Specifications | R600kW/400VAC/50Hz/PF1.0 |
Formation | One load bank(Including dry resistance load, electrical control components, measurement and control system) |
Load step | According to customer needs |
Load connection | Copper bar |
Resistor | Each resistance element: insulation impedance DC1000V/100MΩ above Withstand voltage ac 2000V for 5min Resistance error of each resistance tube:±3% |
Load control | Local manual control, local automatic control or remote automatic control can be selected |
Loading accuracy | Less than or equal to 3% |
Three phase balance | Unbalance degree less than or equal to 3% |
Minimum step | 1kW |
Working mode | Continuous work |
Load protection | Short circuit, overcurrent, high temperature, fan fault protection |
External power | TN-C,380V/50Hz |
Cooling mode | Forced air cooling, side air outlet or top air outlet |
Insulation class | F |
Measurement accuracy | The display accuracy is 0.5,the sampling accuracy is 0.2 |
Electrical parameter display | Three phase voltage, three-phase current, frequency, power, etc |
Load expansion | Parallel expansion of multiple load containers |
Standard | Meet international standard, ship standard, military standard and telecommunication standard |
Transport | The load bank is equipped with load-bearing lifting holes, and the bottom can be equipped with rollers to meet the requirements of long-distance transportation |
Color | Customized |
Ambient temperature | -20℃ to 50℃ |
Humidity | Up to 100% |
Altitude | Up to 2500m |
Atmospheric pressure | 86 to 106kPa |
